Dobinsons Adjustable 1–3 Inch Lift Kit for 2024+ Lexus GX550

Description

• Any lift of 2.5″ or more requires diff drop kit and Aftermarket UCA
• Front Coil Spring Specs:
  • C59-816 (50mm – 2″) Stock Load
  • C59-820 (65mm – 2.5″) Stock Load / (50mm- 2″) 110-220lb Load
• Rear Coil Spring Specs: HYBRID (Non-Hybrid will yield slightly taller lift)
  • C59-883V (Stock Height) Stock Load
    C59-885V (12mm – .5″) Stock Load
    C59-817V (50mm – 2″) 0-100lb Load
    C59-819V (50mm – 2″) 200-400lb Load
    C59-821V (50mm – 2″) 500-700lb Load
    C59-823V (50mm – 2″) 800-1000lb Load
    C59-825V (50mm – 2″) 1100-1300lb Load
• Front Strut Specs:
  • GS59-660 – 0-2″ Lift
  • GS59-440 – 2.5-3″ Lift (Extended Travel) (Aftermarket UCA & Diff Drop Kit REQUIRED)
• WA59-571K – Upper trailing arms – Vehicles with headlight adjuster sensor will require an additional clamp bracket provided by us.
• Complete suspension kit for 4×4 Off Road Use, fine tuned to match the vehicle
• Coils are specifically suited to the additional accessory load (weight) on the vehicle
• Nitrogen Gas Charged Shocks, Superior Design, thicker walls, longer travel
• High Quality Australian-made coil springs, heat treated, fully scragged, powder coated
